150w 170w 180w 190w Stock With SGS Mono Solar Panel

150w 170w 180w 190w Stock With SGS Mono Solar Panel

Short Description:
  • Power: 180w

  • Model NO.: SBM6-36-180

  • Brand: Shaobosolar

  • MOQ: 1*40 HQ

  • Port: Qingdao/Tianjin

  • Payment terms: T/T, L/C

  • Delivery time: Within15days after getting deposit

Product Detail
SBM6-36-180
SBM6-36-180
 Quality parameters
DC withstand voltageMaximum 6000 VDC
Maximum load5400pa
Hail testDiameter 25mm, speed 23m/s
Fire ratingClass C
Mechanical Characteristics
dimensions1480,680,35mm
weight11.7KG
solar cells36 cell in series
cablecopper(2.5mn?)
lengths700mm(-)and700mm(+)
connectorMc4 PlugTyps
glass typehigh transmits,Low lron,3.2mm Tempered Glass
frameAluminium-alloy
Electrical Specifications
ModelSBM6-36-180
Peak power(pmax)180W
Maximum safe current25A
Max.power volt.(vmp)19V
Max.power current(lmp)9.6A
Open circuit volt.(voc)22.5V
Short circuit current(lsc)10.2A
Power tolerance0 〜+5W
Max.system voltage1500V
Series fuse rating(A)15
Number of bypass diode3
Operating temperature-40°C to+85°C
dimensions1480*680*35mm
weight11.7KG
solar cells36 cell in series
cablecopper(2.5mm)
lengths700mm(-)and700mm(+)
connectorMc4 PlugTyps
glass typehigh transmits,Low Iron,3.2mm Tempered Glass
frameAluminium-alloy
DC withstand voltageMaximum 6000 VDC
Maximum load5400pa
Hail testDiameter 25mm, speed 23m/s
Fire ratingClass C
